I have a Benq ET-0005-B touchscreen which works for me Mike

Hi Dan, Please find attached Regards Mike Chauvet_LFS75.ift

Hiya, We have a Benq ET0005-B touchscreen which works with the latest ZerOS software Mike

Hi Gio Please find attached file Please reply if there are any problems Mike Ecoline Laser and Stairville.ift

Hiya I think you are looking at the 7 DMX channel mode - had a look at the fixture file and all looks as expected with the latest console build. What is seen on the LCD is Cyan, Magenta and Yellow though and not Red, Green and Blue. This means the Magenta and Yellow are both at 100 to get Red. Red, Green and Blue can be seen on the monitor in Colour Palettes, Faders. If I've misunderstood, please can you tell me more info including console (and software build) and maybe a show-file Regards Mike

Hi Jimmi I can see what you mean. If you have configured and selected an RGB fixture and press the Colour MFK, the LCD display shows CYM and not RGB. This is a "feature" of the desk and I haven't seen anywhere in the manual if this can be changed, so may be a new feature request to be able to switch between different display modes. Traditional movers tend to have fixed colour wheels or CMY wheels so is likely to be an interesting discussion. The saving grace is that with a monitor attached, displaying the Colour Palettes and then selecting the Fader button shows RGB, CMY and HSV. Regards Mike

Hiya, Please find attached file for 3 and 7 DMX channel modes. I believe the 7 channel mode is Ok but welcome verification Please reply if you find any problems with the file. Regards Mike Chauvet_Slimpar.ift

Hiya, Please find attached file for 3, 4, 6, 9, 12, 18 and 36 DMX channel modes. Unfortunately the 7 DMX channel mode is a bit more involved so I welcome guidance from the Eaton team Please reply if you find any problems with the file. Regards Mike Showtec_Pixelbar.ift

Hiya, Please find attached file for 1, 2 and 7 DMX channel modes. Unfortunately the 9 DMX channel mode is a bit more involved so I welcome guidance from the Eaton team Please reply if you find any problems with the file. Regards Mike Varytec_Par64_5in1.ift

Hiya, Please find attached profile containing both 13 and 25 DMX modes. Please reply if there are any problems Regards Mike Blizzard_QFX.ift

Hiya, Try the attached file for both 16 and 19 DMX channels and reply if there are any problems. Regards Mike Chauvet_Rogue.ift

Hiya, I can't see anything wrong with your fixture file so as long as you are loading the user fixture type (UFT) file as per page 61 of the manual then you should be Ok Regards Mike

Hiya Please find attached file for 13 channel mode. I'm a little confused with the 29 channel mode as if RGBW are on channels 6, 7, 8 and 9, then how do the cluster channels work? Regards Mike Ayra_20140510.ift

Hi Jimmi, Try the attached file and reply with any problems Regards Mike Showtec_20140510.ift

Hiya, In the palettes icons I expect you are seeing IBP - Intensity, Beamshape and Palette? I raised the same to Jon and a fault has been raised. If I remember correctly, this is a feature for the Orb but not the Solution and is only seen if you have the desk in the "Tracking - Advanced" mode. I need to check my emails, but until a fix is available, you could try removing the SMART tagging option whilst recording the palettes which, I believe, will ensure just the individual palette options you are wanting to program are recorded. Regards Mike [Edit] I have checked and this is what I was sent; ZOS-5698 Palettes on Solution record ICBPE info with Smart Tag This is only when in Tracking Mode, with Smart Tag enabled. A quick work around is to disable Smart Tag. Regards Mike

Hiya, I can't find a manual on the web - please can you post the DMX settings or a link to the manual. Many thanks Mike

Hi Michael. Please find attached which has Person 1 to Person 5 inclusive - I think it's Ok but saw errors when saving the file with 16 bit brightness so have set brightness to 8 bit. Hope it's of use. Regards Mike Chauvet QWash419Z.ift

Hi Ben, I have created a file for 3, 4, 8 and 14 DMX channel modes. Reply to the forum if you have any problems with it. Regards Mike Stairville LED Bar4 TriPar.ift

Please find attached file for 2, 3, 5 and 24 DMX modes. Jon: Can you check the 2 and 5 channel personalities over. Many thanks Hope it's of use. Regards Mike Stairville 240 RGB Bar.ift

Hi there, Try the attached file Regards Mike Stairville 240 RGB Bar.ift

Argh - I accidentally pressed this key during a show yesterday It's so easy to say "don't press it" but I was adjusting my moving lights then somehow managed to hit the blackout button, leaving those on stage in darkness - thank goodness the followspots were on the ball The first time in a long while I've accidentally pressed the blackout button but a software switch to enable/disable the button would be advantageous to the console as well as to save my blushes

Roy, From what I can see the M2 mode of the fixture profile has 10 DMX channels; Colour: Color1 Beamshape: Shutter, Gobo1, G1 Rotate, Macro, FX Mac and FX Speed Position: Pan, Tilt, P/T Speed I predominantly use a Solution XL or Frog console so forgive me if this is something that you've already tried, but each aspect whether Colour, Beamshape or Position can have multiple "layers". This means that you press the attribute button, in this case Beamshape, more than once to view all the available options. Hope this is of use. Regards Mike

Chaps, You may find it better if the home positions are set; Dimmer = 255 (Full Brightness) Pan = 128 (Halfway) Tilt = 128 (Halfway) Shutter = 4 (Open) as these will make the fixture start from a mid-position with lamp on when the "home" button is pressed. My only other comment is that the colour should be "Color Wheel" and not "Other Color" but not sure if it makes much difference? Regards Mike

Hi there, Your fixture file looks Ok. Could you be trying to "Update Fixture file"? If so the console is expecting a Global Fixture file format. On the Solution XL, I "Load UFT" - User Fixture Type for custom fixtures that I've created - this may be similar for you? Regarding 5 pin and 3 pin connectivity, the answer is yes - both use pins 1, 2 and 3 with a straight mapping on pins. For 5 pin DMX, pins 4 and 5 were sometimes used for a second universe on other manufacturers equipment but I don't think this was ever established as a standard. Regards Mike

Hi there. Looks like the link needs updating... That said, the 10.12 software and phantom offline editor is available from the Frog Range Software release page; http://zero88.com/support/index.php?/de/Knowledgebase/Article/View/56/257/frog-range-operating-software-release-1012 Regards Mike
